You can buy good quality PKP40 Pneumatic Diaphragm Pump, we are the best distributor from market.
• 1-1/2 in (38.1 mm) end-porting
• High flow – 100 gpm (378 lpm) in a compact, portable size
• Fluid pressure to 120 psi (8.4 bar, 0.84 MPa)
• Patented, high-reliability closed center air valve is online sePKPiceable
• Lube-free operation
• Epoxy-coated air section
• External controller for optional remote operation
• Stainless steel center section for corrosive applications
• Moving fluids ranging from slow moving to very flowable
• Transferring of ingredients from original containers to mixing tanks
• Evacuating liquid concentrates from shipping tankers to holding vessels
• Repackaging fluids from original containers to smaller receptacles
• Concentrated fruit juice
• Pizza paste
• Wine
• Oil
• Jams & jellies
• Pastes and starches
• Corn syrup
• Mineral oil
• Lanolin alcohol
• Glycol
• Pudding
• Chocolate
| PKP40 Pneumatic Diaphragm pump | |
|---|---|
| Technicial Specifications | |
| Max Working Pressure | 100psi(0.7Mpa ,7bar) |
| Max .flow Rate | 90 gpm(340 lpm) |
| Max Reciprocating Speed | 200cpm |
| Max.Suction Height (Dry Sucking) | 5m |
| Max Permitted Grain | 5mm |
| Max Air Consumption | 125scfm(3.5m³/min) |
| Air Inlet size | 1/2 in.npt(f) |
| Air Outlet size | 1/2 in.npt(f) |
| Fluid Inlet size | 11/2 in.npt(f) |
| Fluid Outlet Size | 11/2 in.npt(f) |
| Weight |
Stainless steel pump 29.0kg Aluminum pump 16.0kg |
