Hot PKP50 Pneumatic Diaphragm Pump - Europa Pumps is the best PKP50 Pneumatic Diaphragm Pump supplier.
• 2 in (50.8 mm) end-porting
• Larger ports for more flow – up to 150 gpm (568 lpm)
• Fluid pressure up to 120 psi (8.4 bar, 0.84 MPa)
• Patented, high-reliability closed center air valve is online sePKPiceable
• Lube-free operation
• Epoxy-coated air section
• External controller for optional remote operation
• Moving fluids ranging from very slow moving to very flowable
• Evacuating food process mixing kettles
• Transferring ingredients from original containers to mixing tanks
• Evacuating liquid concentrates from shipping tankers to holding vessels
• Concentrated fruit juice
• Tomato paste
• Wine
• Oil
• Jams & jellies
• Pastes and starches
• Corn syrup
• Glycol
• Thick sauce
• Pudding
• Chocolate
• Fruit filling
| PKP50 Pneumatic Diaphragm pump | |
|---|---|
| Technicial Specifications | |
| Max Working Pressure | 100psi(0.7Mpa ,7bar) |
| Max Flow Rate | 150 gpm(570 lpm) |
| Max Reciprocating Speed | 145cpm |
| Max Suction Height (Dry Sucking) | 5m |
| ax Permitted Grain | 6mm |
| Max Air Consumption | 175scfm(4.9m³/min) |
| Air Inlet size | 1/2 in.npt(f) |
| Air Outlet size | 1/2 in.npt(f) |
| Fluid Inlet size | 2in.npt(f) |
| Fluid Outlet size | 2in.npt(f) |
| Weight |
Aluminum Pump 29.0kg Stainless Steel Pump 47.0kg |
