Europa Pumps is the best PKP80 Diaphragm Pump (Stainless Steel) manufacturer. Offering quality product to global customers.
• 3 in (76.2 mm) ANSI center-porting that is internally threaded 3 npt or bspt
• Bolted leak-free, flanged connections — no clamp bands used
• Large flow paths for high viscosities
• Easy air valve maintenance
• Heavy-duty construction
• Fluid flow up to 275 gpm (1040 lpm)
• Chemical transfers
• Filter press-feed
• Dewatering
• Chemicals
• Bulk paint resins
• Ceramic slip
| PKP80 Diaphragm Pump | |
|---|---|
| Technicial Specifications | |
| Max Working Pressure | 120psi(0.84Mpa ,8.4bar) |
| Max Flow Rate | 275 gpm(1041 lpm) |
| Max reciprocating Speed | 135cpm |
| Max.Suction Height (Dry Sucking) | 5m |
| Max.permitted Grain | 9.4mm |
| Max Air Consumption | 180scfm(90L/s) |
| Air Inlet size | 3/4 in.npt(f) |
| Air Outlet size | 1 in.npt(f) |
| Fluid Inlet size | 3 in.npt(f) |
| Fluid Outlet size | 3 in.npt(f) |
| Weight |
Aluminum pump 77kg; Stainless steel 110.0kg; Ductile Iton 180kg |
