Quality Piston Pump(4:1) suppliers & exporter - all products made.
In the paint,glue ,polyurethane coating automotive ,coating building coating ,oil transportation ,chemical food,pharmaceutical and other industries widely used ,is very suitable for viscous liquid ,corrosive liquid ,liquid containing solid particles or gas bubbles .A variety of materials ,adaptation of wide ,simple installation ,easy maintenance.
1.after close of polishing and surface treatment of stainless steel surface,without damaging the material chemical.
2.Can handle a variety of high viscosity fluid ,strong corrosion resistance.
3.Less maintenance parts ,in the true sense to reduce the maintenance cost.
4.High mechanical life.
| 4:1 Piston Pump | |
|---|---|
| Technical Specifications | |
| Max Working Pressure | 120psi(0.84Mpa ,8.4bar) |
| Max Flow Rate | 65gpm(68lpm) |
| Max .Suction Lift. | 6m |
| Max.Particle Allowed | 3.0mm |
| Max.Air Consumption | 34scfm(0.817m³/min) |
| Air Inlet size | 1/2in.npt(f)1/4in.bsp(f) |
| Fluid Inlet size | 1-1/2in.npt(f)1/4in.bsp(f) |
| Fluid Outlet size | 1in.npt(f)1/4in.bsp(f) |
| Connection | Female Thread/Flange |
| Body Material | SS304/SS306 |
| Ratio | 3:1 |
